AC Centrifugal Fan
R2E225-H063-01B
A versatile 230 V AC centrifugal fan delivering high static pressure for ducted systems, ventilation and cabinet cooling — available for both 50 Hz and 60 Hz mains.
Technical Specifications
| Model | R2E225-H063-01B |
| Impeller Diameter | 225 mm |
| Motor Type | AC external rotor |
| Input Voltage | 230 VAC |
| Frequency | 50 Hz / 60 Hz |
| Rated Current | 0.6 A / 0.9 A |
| Rated Power | 135 W / 180 W |
| Rated Speed | 2600 RPM / 2900 RPM |
| Max Airflow | 1100 m³/h / 1250 m³/h |
| Max Static Pressure | 430 Pa / 675 Pa |
| Bearing | NMB ball bearing |
| Impeller | Plastic |
| Operating Temperature | -30 °C ~ +65 °C |
| Net Weight | 2.8 kgs |
| Certification | CE, UL |
Custom voltages, frequencies and terminations can be specified for OEM builds.
